Pentek Signal Acquisition, DSP & SDR Products

  • PMC/XMC Receiver/Transmitter (ADC/DAC) Cards:
  • picture picture picture picture
    Table 1: Pentek ADC/DAC Cards (PMC/XMC)
    Product Function Channels Resolution Sampling Rate DDC/DUC FPGA Form Factor Notes Product Page
    71630 ADC
    DAC
    1
    1
    12bit
    16bit
    1GHz
    1GHz
    Virtex-6 XMC 71630
    71650 ADC
    DAC
    2
    2
    12/14bit
    16bit
    500/400MHz
    800MHz
    IP
    1ch DUC
    Virtex-6 XMC 71650
    71620 ADC
    DAC
    3
    2
    16bit
    16bit
    200MHz
    800MHz
    IP
    1ch DUC
    Virtex-6 XMC 71620
    71621 ADC
    DAC
    3
    2
    16bit
    16bit
    200MHz
    800MHz
    3ch DDC
    1ch DUC
    Virtex-6 XMC 71621
    71660 ADC 4 16bit 200MHz IP Virtex-6 XMC 71660
    71661 ADC 4 16bit 200MHz 4Ch DDC Virtex-6 XMC 71661
    7158 ADC
    DAC
    2
    2
    12bit
    16bit
    500MHz 800MHz IP
    1ch DUC
    2 x Virtex 5 PMC/XMC 7158
    7156 ADC
    DAC
    2
    2
    14bit
    16bit
    400MHz 800MHz IP
    1ch DUC
    2 x Virtex 5 PMC/XMC 7156
    7150 ADC 4 16bit 200MHz 2 x Virtex 5 PMC/XMC 7150
    7151 ADC 4 16bit 200MHz 256ch DDC 2 x Virtex 5 PMC/XMC 7151
    7152 ADC 4 16bit 200MHz 32ch DDC 2 x Virtex 5 PMC/XMC 7152
    7153 ADC 4 16bit 200MHz 2~4ch WB DDC 2 x Virtex 5 PMC/XMC 7153
    7142 ADC
    DAC
    4
    1
    14bit
    16bit
    125MHz
    500MHz
    1ch DUC 2x Virtex 4 PMC/XMC 7142
    7142-428 ADC
    DAC
    4
    1
    14bit
    16bit
    125MHz
    500MHz
    4Ch DDC IP 2 x Virtex 4 PMC/XMC IP Core-428, DDC IP w/ Intepolation Filter 7142-428
    7141 ADC
    DAC
    2
    2
    14bit
    16bit
    125MHz
    500MHz
    4Ch NB DDC(GC1046)
    1ch DUC
    Virtex II Pro PMC/XMC 7141
    7141-420 ADC
    DAC
    2
    2
    14bit
    16bit
    125MHz
    500MHz
    2Ch WB DDC IP
    1ch DUC
    Virtex 4 PMC/XMC IP Core-420 w/ Intepolation Filter 7141-420
    7141-430 ADC
    DAC
    2
    2
    14bit
    16bit
    125MHz
    500MHz
    256Ch NB DDC IP
    1ch DUC
    Virtex II Pro PMC/XMC IP Core-430 7141-430
    7141-703 ADC
    DAC
    2
    2
    14bit
    16bit
    125MHz
    500MHz
    DDC GC4016 or DDC IP
    1ch DUC
    Virtex 4 PMC/XMC Rugged & Conduction-cooled version 7141-703
    7140 ADC
    DAC
    2
    2
    14bit
    16bit
    105MHz
    500MHz
    4ch NB DDC(GC4016)
    1ch DUC
    Virtex II Pro PMC/XMC 7140
    7140-420 ADC
    DAC
    2
    2
    14bit
    16bit
    105MHz
    500MHz
    2Ch WB DDC IP
    1ch DUC
    Virtex 4 PMC/XMC IP Core-420 w/ Intepolation Filter 7140-420
    7140-430 ADC
    DAC
    2
    2
    14bit
    16bit
    105MHz
    500MHz
    256Ch NB DDC IP
    1ch DUC
    Virtex II Pro PMC/XMC IP Core-430 7140-430
    7131 ADC 4 14bit 105MHz 16ch NB DDC(GC4016) Virtex II PMC Rugged option available 7131
    7190 Clock Synthesizer 8 PMC 7190

  • PCI-Express/PCI Receiver/Transmitter(ADC/DAC) Cards:
  • picture picture picture picture
    Table 2: Pentek ADC/DAC Cards (PCI-Express/PCI)
    Product Function Channels Resolution Sampling Rate DDC/DUC FPGA Form Factor Notes Product Page
    7858 ADC
    DAC
    2
    2
    12bit
    16bit
    500MHz 800MHz IP
    1ch DUC
    2 x Virtex 5 PCIe Gen2.0 x8 7858
    7758D ADC
    DAC
    4
    4
    12bit
    16bit
    500MHz 800MHz IP
    2ch DUC
    4 x Virtex 5 Full-length PCIe Gen2.0 x8 7758D doubles the resources of 7758 7758D
    7856 ADC
    DAC
    2
    2
    14bit
    16bit
    400MHz 800MHz IP
    1ch DUC
    2 x Virtex 5 PCIe Gen2.0 x8 7856
    7756D ADC
    DAC
    4
    4
    14bit
    16bit
    400MHz 800MHz IP
    2ch DUC
    4 x Virtex 5 Full-length PCIe Gen2.0 7756D doubles the resources of 7756 7756D
    7850 ADC 4 16bit 200MHz 2 x Virtex 5 PCIe Gen2.0 x8 7850
    7750D ADC 8 16bit 200MHz 4 x Virtex 5 Full-length PCIe Gen2.0 7750D doubles the resources of 7750 7750D
    7851 ADC 4 16bit 200MHz 256ch DDC 2 x Virtex 5 PCIe Gen2.0 x8 7851
    7751D ADC 8 16bit 200MHz 512ch DDC 4 x Virtex 5 Full-length PCIe Gen2.0 x8 7751D doubles the resources of 7751 7751D
    7852 ADC 4 16bit 200MHz 32ch DDC 2 x Virtex 5 PCIe Gen2.0 x8 7852
    7752D ADC 8 16bit 200MHz 64ch DDC 4 x Virtex 5 Full-length PCIe Gen2.0 7752D doubles the resources of 7752 7752D
    7853 ADC 4 16bit 200MHz 2~4ch WB DDC 2 x Virtex 5 PCIe Gen2.0 x8 beamforming 7853
    7753D ADC 8 16bit 200MHz 4~8ch WB DDC 4 x Virtex 5 Full-length PCIe Gen2.0 beamforming 7753D
    7842 ADC
    DAC
    4
    1
    14bit
    16bit
    125MHz
    500MHz
    1ch DUC 2x Virtex 4 PCIe Gen2.0 x8 7842
    7742D ADC
    DAC
    8
    2
    14bit
    16bit
    125MHz
    500MHz
    2ch DUC 4 x Virtex 4 Full-length PCIe Gen2.0 x8 7742D
    7842-428 ADC
    DAC
    4
    1
    14bit
    16bit
    125MHz
    500MHz
    4Ch DDC IP 2 x Virtex 4 PCIe Gen2.0 x8 IP Core-428, DDC IP w/ Intepolation Filter 7842-428
    7742D-428 ADC
    DAC
    8
    2
    14bit
    16bit
    125MHz
    500MHz
    8Ch DDC IP 4 x Virtex 4 Full-length PCIe Gen2.0 x8 IP Core-428, DDC IP w/ Intepolation Filter 7842D-428
    7841 ADC
    DAC
    2
    2
    14bit
    16bit
    125MHz
    500MHz
    4Ch NB DDC(GC1046)
    1ch DUC
    Virtex II Pro PCIe 7841
    7741D ADC
    DAC
    4
    4
    14bit
    16bit
    125MHz
    500MHz
    8Ch NB DDC(GC1046)
    2ch DUC
    2 x Virtex II Pro Full-length PCIe 7741D
    7841-420 ADC
    DAC
    2
    2
    14bit
    16bit
    125MHz
    500MHz
    2Ch WB DDC IP
    1ch DUC
    Virtex 4 PCIe IP Core-420 w/ Intepolation Filter 7841-420
    7741D-420 ADC
    DAC
    4
    4
    14bit
    16bit
    125MHz
    500MHz
    4Ch WB DDC IP
    2ch DUC
    2 x Virtex 4 Full-length PCIe IP Core-420 w/ Intepolation Filter 7741D-420
    7841-430 ADC
    DAC
    2
    2
    14bit
    16bit
    125MHz
    500MHz
    256Ch NB DDC IP
    1ch DUC
    Virtex II Pro PCIe IP Core-430 7841-430
    7741D-430 ADC
    DAC
    4
    4
    14bit
    16bit
    125MHz
    500MHz
    512Ch NB DDC IP
    2ch DUC
    2 x Virtex II Pro Full-length PCIe IP Core-430 7741D-430
    7840 ADC
    DAC
    2
    2
    14bit
    16bit
    105MHz
    500MHz
    4ch NB DDC(GC4016)
    1ch DUC
    Virtex II Pro PCIe/PCI 7840
    7740D ADC
    DAC
    4
    4
    14bit
    16bit
    105MHz
    500MHz
    8ch NB DDC(GC4016)
    2ch DUC
    2 x Virtex II Pro Full-length PCIe/PCI 7740D
    7890 Clock Synthesizer 8 PCIe 7890
  • VME/VXS Receiver/Transmitter(ADC/DAC) Cards:
  • picture picture picture picture
    Table 3: Pentek ADC/DAC Cards (VME/VXS)
    Product Function Channels Resolution Sampling Rate DDC/DUC FPGA Form Factor Notes Product Page
    6826 ADC 2 10bit 2GS/s Virtex II Pro VME/VXS Commercial or Conduction-cooled 6826
    6823 ADC 4 8bit 500MHz 4 x Virtex 4 VME 6823
    6822 ADC 2 12bit 215MHz 2 x Virtex II Pro VME/VXS FPDP II output 6822
    6821 ADC 1 12bit 215MHz 2 x Virtex II Pro VME/VXS FPDP II output 6821
    6821-422 ADC 1 12bit 215MHz 2ch WB DDC IP(296MHz) 2 x Virtex II Pro VME/VXS FPDP II output 6821-422
    6802 ADC 32 24bit 1KHz~
    216KHz
    VME FPDP output 6802
    6890 Clock Distribution 6890
  • CompactPCI Receiver/Transmitter(ADC/DAC) 3U/6U Cards:
  • picture picture picture picture
    Table 4: Pentek CompactPCI ADC/DAC Cards (3U/6U)
    Product Function Channels Resolution Sampling Rate DDC/DUC FPGA Form Factor Notes Product Page
    7358 ADC
    DAC
    2
    2
    12bit
    16bit
    500MHz 800MHz IP
    1ch DUC
    2 x Virtex 5 3U cPCI 7358
    7258D ADC
    DAC
    4
    4
    12bit
    16bit
    500MHz 800MHz IP
    2ch DUC
    4 x Virtex 5 6U cPCI 7258D
    7356 ADC
    DAC
    2
    2
    14bit
    16bit
    400MHz 800MHz IP
    1ch DUC
    2 x Virtex 5 3U cPCI 7356
    7256D ADC
    DAC
    4
    4
    14bit
    16bit
    400MHz 800MHz IP
    2ch DUC
    4 x Virtex 5 6U cPCI 7256D
    7350 ADC 4 16bit 200MHz 2 x Virtex 5 3U cPCI 7350
    7250D ADC 8 16bit 200MHz 4 x Virtex 5 6U cPCI 7250D
    7351 ADC 4 16bit 200MHz 256ch DDC 2 x Virtex 5 3U cPCI 7351
    7251D ADC 8 16bit 200MHz 512ch DDC 4 x Virtex 5 6U cPCI 7251D
    7352 ADC 4 16bit 200MHz 32ch DDC 2 x Virtex 5 3U cPCI 7352
    7252D ADC 8 16bit 200MHz 64ch DDC 4 x Virtex 5 6U cPCI 7252D
    7353 ADC 4 16bit 200MHz 2~4ch WB DDC 2 x Virtex 5 3U cPCI 7353
    7253D ADC 8 16bit 200MHz 4~8ch WB DDC 4 x Virtex 5 6U cPCI 7253D
    7342 ADC
    DAC
    4
    1
    14bit
    16bit
    125MHz
    500MHz
    1ch DUC 2x Virtex 4 3U cPCI 7342
    7242D ADC
    DAC
    8
    2
    14bit
    16bit
    125MHz
    500MHz
    2ch DUC 4 x Virtex 4 6U cPCI 7242D
    7342-428 ADC
    DAC
    4
    1
    14bit
    16bit
    125MHz
    500MHz
    4Ch DDC IP 2 x Virtex 4 3U cPCI IP Core-428, DDC IP w/ Intepolation Filter 7342-428
    7242D-428 ADC
    DAC
    8
    2
    14bit
    16bit
    125MHz
    500MHz
    8Ch DDC IP 4 x Virtex 4 6U cPCI IP Core-428, DDC IP w/ Intepolation Filter 7242D-428
    7341 ADC
    DAC
    2
    2
    14bit
    16bit
    125MHz
    500MHz
    4Ch NB DDC(GC1046)
    1ch DUC
    Virtex II Pro 3U cPCI 7341
    7241D ADC
    DAC
    4
    4
    14bit
    16bit
    125MHz
    500MHz
    8Ch NB DDC(GC1046)
    8ch DUC
    2 x Virtex II Pro 6U cPCI 7241D
    7341-420 ADC
    DAC
    2
    2
    14bit
    16bit
    125MHz
    500MHz
    2Ch WB DDC IP
    1ch DUC
    Virtex 4 3U cPCI IP Core-420 w/ Intepolation Filter 7341-420
    7241D-420 ADC
    DAC
    2
    2
    14bit
    16bit
    125MHz
    500MHz
    4Ch WB DDC IP
    2ch DUC
    2 x Virtex 4 6U cPCI IP Core-420 w/ Intepolation Filter 7241D-420
    7341-430 ADC
    DAC
    2
    2
    14bit
    16bit
    125MHz
    500MHz
    256Ch NB DDC IP
    1ch DUC
    Virtex II Pro 3U cPCI IP Core-430 7341-430
    7241D-430 ADC
    DAC
    4
    4
    14bit
    16bit
    125MHz
    500MHz
    512Ch NB DDC IP
    1ch DUC
    2 x Virtex II Pro 6U cPCI IP Core-430 7241D-430
    7340 ADC
    DAC
    2
    2
    14bit
    16bit
    105MHz
    500MHz
    4ch NB DDC(GC4016)
    1ch DUC
    Virtex II Pro 3U cPCI 7340
    7240D ADC
    DAC
    4
    4
    14bit
    16bit
    105MHz
    500MHz
    8ch NB DDC(GC4016)
    2ch DUC
    2 x Virtex II Pro 6U cPCI 7240D
    7340-420 ADC
    DAC
    2
    2
    14bit
    16bit
    105MHz
    500MHz
    2Ch WB DDC IP
    1ch DUC
    Virtex 4 3U cPCI IP Core-420 w/ Intepolation Filter 7340-420
    7240D-420 ADC
    DAC
    4
    4
    14bit
    16bit
    105MHz
    500MHz
    4Ch WB DDC IP
    2ch DUC
    2 x Virtex 4 6U cPCI IP Core-420 w/ Intepolation Filter 7240D-420
    7340-430 ADC
    DAC
    2
    2
    14bit
    16bit
    105MHz
    500MHz
    256Ch NB DDC IP
    1ch DUC
    Virtex II Pro 3U cPCI IP Core-430 7340-430
    7240D-430 ADC
    DAC
    4
    4
    14bit
    16bit
    105MHz
    500MHz
    512Ch NB DDC IP
    1ch DUC
    2 x Virtex II Pro 6U cPCI IP Core-430 7240D-430
    7331 ADC 4 14bit 105MHz 16ch NB DDC(GC4016) Virtex II 3U cPCI Rugged option available 7331
    7231D ADC 8 14bit 105MHz 32ch NB DDC(GC4016) 2 x Virtex II 6U cPCI Rugged option available 7231D
