Stream1800 1,800MHz 12bit Recorder System


    Stream1800 is a turn-key IF/RF recording system ideal for Radar, SAR Radar, and DBF-SAR Radar applications.

    Features and Specifications of Record

  • - 4Ch 1,800MHz 12bit ADC
  • - 2Ch 3,600MHz 12bit ADC
  • - Support wideband DDC, DDC BW 90MHz to 360MHz
  • - Triggered or Continuous Acquisition Mode
  • - Trigger Rate: up to 15KHz
  • - Trigger Length: up to 256K Samples
  • - 4Ch acquisition in synchronization
  • - Phase coherency for each trigger
  • - Supports Real and Complex Recording Mode
  • - Intuitive GUI for easy control
  • - Linux or Windows OS
  • - Recorded into single or multiple files
  • - Up to 8Ch 1,800MHz ADC
  • - Up to 4Ch 3,600MHz ADC

    • Stream series Recorder is based on 10+ years of experience in data recording technology, and its key focus is on data continuity, signal fidelity and system quality. This system has passed stringent acceptance test and provides user with a high fidelity signal acquisition system.

    Leveraging high quality and comprehensive signal acquisition products, Stream series offers customers a complete series of turn-key solutions for different sampling rate, channel count and resolution requirements. It supports Windows OS as standard, and Linux as an option. picture

    Fig 2: DDC mode, Tune to 70MHz IF, 20MHz BW

    Stream1800 support Triggered Acquisition mode with flexible Trigger Rate and Trigger Length parameters, which is very useful for Radar (i.e. SAR) applications. The system can customize to user's different requirements and integrate into user's larger systems, and supports either Windows or Linux OS.

    The Stream1800 Record System can support up to 8Ch 1,800MHz or 4Ch 3,600MHzp synchronized Recording.

    Stream Data Recorder and Playback Solution
    Product Description
    Stream200 Record and Playback 3Ch 16bit 200MHz ADC Record (with DDC)
    2Ch 16bit 400MHz DAC Playback(with DUC)
    Stream500 Record and Playback 2Ch 12bit 500MHz ADC/14bit 400MHz ADC Record
    2Ch 16bit 500MHz DAC Playback
    Stream1800 Record 2Ch 12bit 1.8GHz ADC Record
    1Ch 12bit 3.6Ghz ADC Record
    Stream3000 sFPDP Record and Playback 4Ch/8Ch sFPDP Record and Playback
    Stream5000 Aurora Record and Playback 4Ch/8Ch Aurora Recorder and Playback
    Stream6000 RF Record 4Ch RF Record/Playback
    Instant Bandwidth Up to 56MHz
    WaveGen1250 Playback 4Ch 16bit 1.25GHz DAC Playback
